Tuxedo · Mobile Column Lifts
HEAVY-DUTY MOBILE COLUMN LIFTS
Request a quote
Heavy Duty Mobile Column Lifts • 24VDC Battery Operation with Onboard Charging System • Communication Cable with Retractable Cable Reels • U-Shape Wiring Configuration for quick vehicle entry & exiting • Convenient Operation from any Column • Independent Mechanical Locking System • PLC & Optical Encoder provides continuous synchronization for Columns • Easily positioned with Pallet Jack type devic
72,000 lb capacity
Available — freight in 5–10 days
Authorized dealer pricing
Nationwide U.S. shipping
Specifications
- shipping
- Ship Weight: 1584 lbs per Column
- max height
- 155.5 in
- min height
- 88.6 in
- installation
- Indoors
- lifting time
- 100 s
- power source
- 12VDC Sealed Deep Cycle Battery (BCI Group 31, AH-105)
- lowering time
- 60 s
- overall width
- 44.1 in
- raised height
- 67.1 in
- shipping weight
- 1584 lbs
- lifting capacity
- 72000 lbs
Most lifts ship LTL freight with lift-gate. Installation and certification available — ask sales for a turnkey quote.
